BSCORE DEV PEDAL PCB

$14.99

Printed circuit board for Blackstomp’s digital effect development pedal (BSCORE DEV PEDAL), which uses BSCORE module as the digital processing core component (BSCA1SAC101-MOD  or BSCA1SES8388-MOD). Designed for 125B enclosure using 100% through hole components.



Click on the product tabs below to find the description and the build document.

8 in stock

SKU: BSCDEVPEDAL-PCB Categories: ,

Description

BSCORE DEV PEDAL PCB is a printed circuit board for Blackstomp’s digital effect development pedal (BSCORE DEV PEDAL), which uses BSCORE module as the digital processing core component (BSCA1SAC101-MOD  or BSCA1SES8388-MOD). Designed for 125B enclosure using 100% through hole components.



SPECIFICATION

  • >> Material: FR4-Standard Tg 130-140C
  • >> PCB thickness: 1.6 mm
  • >> PCB size: 85.7 mm* 59.7 mm
  • >> Appearance quality: IPC Class 2 Standard
  • >> Surface finish: lead-free-HASL-RoHS
  • >> PCB color: black
  • >> Silkscreen: white



BONUSES

  • >> Printed drill template
  • >> Printed vinyl knob label sticker for 125B enclosure
  • >> 2.54 mm pitch 2×15 pin right angle male header



Build Document



bscore-dev-pedal-pcb-build-manual
