ESP32-A1S Guitar Multi-Effect Engine with Microphone and MIDI I/O

Since the release of ESP32 by Espressif, many application-specific modules based on this chip are produced. For example, Ai-Thinker produce image processing module with artificial intelligence support for image recognition. In the audio processing area, one interesting product by Ai-Thinker is the ESP32-A1S module. Because of the integrated AC101 codec inside, this module enable very compact and low cost solution […]

Read more

DIY Reverb Pedal Circuit: Spring-Hall Reverb with PT2399 IC

Introduction to Reverberation Before getting into the design of DIY reverb pedal circuit, lets see the concept of reverberation first. Real reverberation happens in a performance chamber when the walls and every object inside reflects the sound back and forth. As the sound bounces back and forth in three dimensional space, the reflections creates more and more complex pattern. The […]

Read more

DSKIT-P12BME1 Deepstomp DIY Programmable Guitar Effect Pedal Kit with Bluestomp ME-1 Multi-Effect Core

Free shipping worldwide only for US$59 Buy DSKIT-P12BME1 for US$59 (Accept Paypal or credit cards) PRODUCT PACKAGE AND CONTENTS PRODUCT DESCRIPTION Deepstomp DIY Digital Guitar Pedal Kit with Bluestomp ME-1 Multi-Effect CPU module is a components kit containing complete unassembled parts to build a multi-effect stompbox/pedal featured with: Guitar chromatic tuner Integrated noise gate expander and compressor (with off-level and […]

Read more

DSKIT-P12 Deepstomp DIY Programmable Guitar Effect Pedal Kit (without The CPU Module)

Description Deepstomp DIY Digital Guitar Pedal Kit without the CPU module. Kit Contents Pedal Enclosure Case Molded plastic material (2 mm thick) Size: 4 mm x 6 mm x 12 mm Vinyl label sticker Deepstomp Main Board PCB (DSPCB-12) Components Package Components Package Contents Resistors R1,R2,..,R42 ……. 42 x Resistors Swicth, potentiometer, and knobs VR1,2 …… 2 x 10K Potentiometer […]

Read more

HM936D-PCB Digital Soldering Station PCB

Description HM936D-PCB is a double-side printed circuit board for soldering station circuit that support power LED indicator, heater driver indicator, up-down push button switch interface, RTD/Thermocouple selection jumper or switch, and 3 digit seven segment display for displaying both set point and the actual temperature. Documents Hardware circuit schematic diagram and system design reference PCB manual (only in bahasa Indonesia)

Read more

DSPCB-12 Deepstomp Main Board PCB Circuit Version 1.2

Description Description DSPCB-12 is a printed circuit boards package for Deepstomp main board (circuit version: 1.2). It contains two pieces of PCBs (panel PCB and CPU mounting PCB). PCB Specification PCB material: FR4 1.5 mm Layer count: 2 Plated through hole: yes Solder adhesive coating: HASL (with lead) Solder mask: yes Silk screen (label) Size : 53 mm x 97 […]

Read more

HM936D-AM8 Digital Soldering Station Controller Chip

Product Description HMC936D-AM8 is a controller chip for HM-936D digital soldering station controller board. The controller is implemented using ATMEGA8 microcontroller, programmed with lock protection to disable the chip for being read or modified. It runs on 8MHz  internal factory calibrated RC clock, so there is no need to provide XTAL and its related capacitors. The operational menu, custom sensor calibration […]

Read more

DSCPU-BME1 Bluestomp ME-1 Digital Multi-Effect Deepstomp Core

Description Bluestomp ME-1 is a programmable (reprogrammable) Deepstomp CPU board with embedded multi-effect application, protected with license code, encryption, authentication, authorization, and digital signature. Features (Current Version 1.0) Included with Deepstomp’s Standard Effects (V1.5): Chromatic guitar tuner Integrated noise gate expander and compressor module Included Advanced Effects: Distortion (with overdrive, fuzz, and fold-back modes, without tone control) Tremolo modulator (with […]

Read more

Firmware Updates

Note that the license key of the device will be required to access the firmware download if the update is available. Deepstomp Core Bluestomp ME-1 Digital Multi-Effect Latest version: 1.0 (Release date: April 29 2019) Update status: No available update at his time Deepstomp Core Bluestomp AR-1 Advanced Digital Effect Latest version: 1.0 (Release date: April 29 2019) Update status: […]

Read more
